RIGOL Chapter 1 Quick Start
1-10 RSA5000 User Guide
Tip:
Click the function keypad icon at the right corner of the LCD or finger-touch it,
and then the function keypad that corresponds to the specified keys on the front
panel appears. At this time, you can operate the instrument with the function
keypad.
Utility Function Keys on the Front Panel
Table 1-3 Descriptions of Utility Function Keys on the Front Panel
Locks all the keys (except the Power key) on the front panel.
Locks the touch screen of the instrument.
In the multi-window display mode, press this key to select the
specified window to zoom it in or out.
In the multi-window display mode, press this key to switch the
window.
