Chapter 6 System Function RIGOL
RSA5000 User Guide 6-13
Recall
RSA5000 allows you to recall various types of files saved to the internal or external
storage memory.
Press Recall on the front panel to enter the file recalling menu. The available file
types include: State, Trace+State, Measurement Data, Limit, and FMT (only available
for RTSA).
State
Press State to enter the state recalling menu. The state can be recalled from the
register or the file.
1. Recall
Press File Explorer to enter the file manager interface. Select a file and then
press Recall to recall the file from a register or a file.
2. Register1 through Register16
When any one of the items from Register1 to Register16 is selected, the state of
the specified register will be recalled.
Trace+State
Press Trace+State to enter the trace+state recalling menu. The state of the
instrument and the selected trace can be recalled from a register or a file.
1. Recall
Press File Explorer to enter the file manager interface. Select a file and then
press Recall to import the file.
2. To Trace
Selects the trace+state file or the trace data of the register to recall them to the
selected trace.
3. Register1 through Register16
When any one of the items from Register1 to Register16 is selected, the state of
the specified register will be recalled.
