Rigol RSA5000 Series User Manual

RIGOL Chapter 5 Shortcut Key
5-4 RSA5000 User Guide
Sweep Points
801
--
Sweep Time
Auto, 1 ms
--
Acq Time
--
Auto, 31.9960
ms
Auto, 21.9855
ms
Sweep Time Mode
Continuous
Continuous
Sweep Time Rule
Normal
--
Trigger
Trigger Source
Free Run
Free Run
Trigger Holdoff
Off, 100 ms
Off, 100 ms
Auto Trig
Off, 100 ms
Off, 0 us
Slope
Positive
Positive
Trig Delay
Off, 1 us
Off, 1 us
Trigger Level
-25 dBm
--
Acq/Trigger
--
1
Power
--
0 dB
Mask Type
--
Upper
Trigger Mask
--
Upper
Trigger Criteria
--
Enter
Active Mask
--
Upper
Frequency
--
0 Hz
Amplitude
--
0 dB
Build From Trace
--
Trace1
X Offset
--
0 Hz
Y Offset
--
0 dB
X Axis Type
--
Relative
Y Axis Type
--
Relative
Trace
Selected Trace
Trace1
Trace1
--
Trace Type
Clear Write
Clear Write
--
Trace Det
Normal
Pos Peak
Pos Peak
Detector Auto
On
On
On
Trace Update
On
On
On
Trace Display
On
On
On
Math Function
Off
Off
--
Op1
Trace5
Trace5
--
Op2
Trace6
Trace6
--
Offset
0 dB
0 dB
--
Reference
0 dB
0 dB
--
TG
[1]
Output
Off
--
Amplitude
-40 dBm
--
Amplitude Offset
0 dB
--
Normalize
Off
--
Reference Level
0 dB
--
