Rigol RSA5000 Series User Manual

Chapter 5 Shortcut Key RIGOL
RSA5000 User Guide 5-7
Measure Setup
[2]
(RTSA)
Normal
Avg Number
100
Test Limits
Off
Select Limit
Limit1
Limit State
Off
Test Trace
Trace1
Limit Type
Upper
X to CF
Relative
Y to Ref
Relative
Margin
Off, 0 dB
Frequency
0 Hz
Amplitude
0 dBm
Build From Trace
Trace1
X Offset
0 Hz
Y Offset
0 dB
Density
Avg Number
100
Persistence
300 ms
Pers Inf
Off
Color Palettes
Warm
Highest Density Hue
100
Lowest Density Hue
0
Curve Nonlinearity
75
Hue Truncate
Off
Spectrogram
Avg Number
100
Display Trace
0
Trace Selection
Trace Number
Couple Marker Trace
Off
Ref Hue
0
Ref Hue Pos
100
Bottom Hue Pos
0
SSC
Max Hold
Off
Mark Line1
Off, 3.23 GHz
Marker Line2
Off, 3.27 GHz
Pass/Fail
Off
Signal
1
Ampt Up
-100 dBm
Ampt Down
-100 dBm
Marker
Selected Marker
Marker1
Marker1
Marker1
Marker Mode
Position
Position
Position
