Chapter 6 System Function RIGOL
RSA5000 User Guide 6-19
2) Color Type
Press this key to select the color of the current screen image to be "Normal"
or "Inverted".
FMT (only available for RTSA)
Press FMT to enter the FMT file saving menu. Save the selected FMT file to the file.
1. Save
Press this key to save the currently selected FMT file in the default filename or
user-defined filename.
The default filename is determined by the following methods:
⚫ If you haven't input a filename by pressing the Save As key, its default
filename is FMT<n>.csv. Wherein, n refers to the file number of the
filenames that are named based on the naming mode in the current file
directory. The value of <n> is the existing maximum file number plus 1.
⚫ If you have pressed the Save As key to input the filename abc, then the file
is saved to be "abc.csv". After that, press the key again, another file is
saved automatically with the filename "abc1.csv".
2. Save As
Press this key and then use the numeric keypad on the front panel to input the
filename. Then, press Save to save the corresponding FMT file.
You can also touch the screen or use the mouse to touch or click the Save As
menu, and then input the filename with the keypad.
3. Select FMT
Selects the FMT to be saved.
Quick Save Path
Open the file explorer interface, and then select the corresponding path. Press the
Quick Save Path softkey to set the current path to be the quick save path.
