Rigol RSA5000 Series User Manual

Chapter 2 Functions of the Front Panel of GPSA RIGOL
RSA5000 User Guide 2-47
Table 2-34 Adjacent Channel Bandwidth for ACP Measurement
Parameter
Remarks
Default
2 MHz
Range
33 Hz to 2.5 GHz
Unit
GHz, MHz, kHz, Hz
Knob Step
adjacent channel bandwidth/100,
Min = 1 Hz
Left/Right Arrow Key Step
Up/Down Arrow Key Step
at 1-1.5-2-3-5-7.5 step
6. Chan Spacing
Sets the spacing between the center frequency of the main channel and that of
the adjacent channels.
⚫ Adjusting this parameter will also adjust the distance between the
upper/lower channel and the main channel.
⚫ You can use the numeric keys, the knob, or arrow keys to modify this
parameter; you can also use the touch screen to modify the parameter.
Table 2-35 Channel Spacing for ACP Measurement
Parameter
Remarks
Default
2 MHz
Range
33 Hz to 2.5 GHz
Unit
GHz, MHz, kHz, Hz
Knob Step
channel spacing/100, Min = 1 Hz
Left/Right Arrow Key Step
Up/Down Arrow Key Step
at 1-1.5-2-3-5-7.5 step
For details about the Auto Couple and Meas Preset menus, refer to their
descriptions on Page 2-44.
