RIGOL Chapter 2 Functions of the Front Panel of GPSA
2-50 RSA5000 User Guide
the span of the channel according to your needs, and then press Add
Channel to add a channel.
Table 2-37 Channel Span
Parameter
Remarks
Default
3 GHz
Range
10 Hz to 2*Min[(channel
frequency – start frequency),
(stop frequency - channel
frequency)]
Unit
GHz, MHz, kHz, Hz
Knob Step
channel span/100, Min = 1 Hz
Left/Right Arrow Key Step
Up/Down Arrow Key Step
at 1-1.5-2-3-5-7.5 step
5) Add Channel
⚫ If a channel is selected in the table editing table, pressing this key can
add a channel that is the same as the selected channel to the table.
⚫ When no channel is selected in the channel editing table, pressing this
key can add a channel whose center frequency is the same as the value
under Channel Freq and whose span is the same as the value under
Channel Span.
Note that when you select "Off" under Channel Sheet, this Add Channel
menu is also valid.
6) Delete Channel
Press this key to delete the currently selected channel.
Note that when you select "Off" under Channel Sheet or no channel is
selected, this Delete Channel menu is invalid.
7) Deletes All Channels
Press Del All Channel to clear data in the channel editing table, i.g.
deleting all the channels.
Note that when you select "Off" under Channel Sheet, this Del All
Channel menu is also valid.
For details about the Auto Couple and Meas Preset menus, refer to their
descriptions on Page 2-44.
