Document Overview
This manual is designed to guide you to properly test the performance specifications of RIGOL
RSA5000 series real-time spectrum analyzer in GPSA mode. For the operation methods mentioned in
the test procedures, refer to User Guide of this product.
Main Contents in this Manual:
Chapter 1 Overview
This chapter introduces the preparations before performing the performance verification tests and
the notices.
Chapter 2 Performance Verification Test
This chapter introduces the limit, test devices required as well as the test method and procedures of
each performance specification.
Appendix Test Record Form
The appendix provides a test record form for users to record the test results and judge whether each
performance specification can meet the requirement.
Format Conventions in this Manual:
Front panel key: The key on the front panel is denoted by the format of "Key Name (Bold) + Text
Box" in the manual. For example, FREQ indicates the "FREQ" key on the front panel.
Menu softkey: The menu softkey is denoted by the format of "Menu Word (Bold) + Character
Shading". For example, Center Freq denotes the "Center Freq" menu softkey under FREQ.
Operation step: The next step of operation is denoted by an arrow "→". For example, FREQ →
Center Freq denotes that first press FREQ, and then press the Center Freq softkey.
Content Conventions in this Manual:
The RSA5000 series spectrum analyzer includes the following models. This manual takes RSA5065N
as an example to illustrate the test methods for the performance verification of the RSA5000 series.
