Replacing - Faulty PAS Sensor
Step 1 - Remove the axle bolt using an 8mm Allen key
Step 2 - Use a crank puller to remove the crank
Step 3 - Remove the pedal
Step 5 - Gently use a flat head screw driver to
wedge and pry the PAS sensor (be very gently)
Step 6 - Fully remove the PAS from the axle by wiggling by hand
Step 7 - Inspect the PAS sensor teeth for damage
All teeth must be in good condition, (A) No damage to teeth
Step 8 - (B) Align teeth and re-install the PAS sensor onto the axle
(C) The sensor cable must be at the base, towards the ground
Step 9 - Check the PAS sensor is snugly fit with no play.
(D) No gaps, between sensor and frame.
(E) No movement, sensor remains firm when twisted.
Step 10 - Re-install the crank arm and tighten the 8mm
