OVERVIEW
The Ring Pure Sine Wave (PSW) inverter provides a 230 volt supply which closely replicates the domestic
mains supply. This makes it ideal for powering more sensitive equipment which may not be compatible with
traditional Modified Sine Wave (MSW) inverters.
2
1. CONTENTS
2. FEATURES
1. Mains 230V AC outlet(s)
2. Power on/off switch
3. Power indicator
4. Over load indicator
5. Over temperature indicator
6. Remote control socket*
7. USB Port*
8. Battery positive (+)
connection
9. Battery negative (-)
connection
10. Earth connection
11. Cooling fan(s)
12. Hard wired 230V AC outlets
13. Test button for integral RCD
* - Only fitted on certain
models
Modified Sine Wave (MSW) Pure Sine Wave (PSW)
Standard Features
Additional features (RCD Models only)
1
1
2
6
7
8
8
9
3
4
5
11
10
12
13
11
3. Battery Clamps
4. Protective Covers2. Connecting Cables
5. 3 x Cable Glands
(RCD models only)
1. Inverter
