8. SPECIFICATIONS
Model 600 Watt 1000 Watt 2000 Watt 3000 Watt
Continuous Power (up to 12 hours) 600W 1000W 2000W 3000W
Surge Power (up to 1 second) 1200W 2000W 4000W 6000W
Output Voltage 230V AC±10%
Output Frequency 50Hz
Output Waveform Pure Sine Wave
Input Voltage Range 12volt: 10V - 16V
24volt: 20V - 30V
Efficiency > 85%
No Load Current Draw 12volt: < 0.6amp < 1.3amp < 1.5amp < 1.5amp
24volt: - < 1.0amp < 1.0amp -
RCD tripping * - 30mA -
Low Battery Alarm 12volt: 10.5 ± 1 volt
24volt: 21.0 ± 1 volt
Low Battery Shutdown 12volt: 10.0 ± 1 volt
24volt: 20.0 ± 1 volt
Thermal protection 60± 10
o
C
USB Port 2amp (max) 2amp (max) - -
Dimension (L x W x H) 255 x 225 x 91 394 x 224 x 96 385 x 290 x 96 520 x 286 x 96
Weight 3.5kg 6.3kg 7.7kg 10.8kg
* - only fitted to models RINVPR1000/RINVPR1024/RINVPR2000/RINVPR2024
