ring RBGDC50 - Controls


1. PresstoturndashcameraOn-O/TurnNightVisionLEDsOn-O
2.OK–PresstoConrmaselecon/Start/Stoparecording
3.MENU–PresstoopentheMenuSystem
4. s–PresstomoveUp/ZoomIn
5. t–PresstomoveDown/ZoomOut
6.MODE–PresstoselectVideoMode/Lockcurrentrecording
7.LCDDisplay
8.Speaker
9.Indicator–Green=On,Red=Charging
10.Mounngslot–Aachwindscreenmounthere
11.Lens
12.NightVisionLEDs
13.AVInterface–ForusewithAVcable(notincluded)
14.HDMIInterface–ForusewithHDMIcable(notsupplied)
15.USBInterface–UsetoconnecttoaPCwithUSBcable(supplied)
16.Microphone
17.MemoryCardSlot–InsertMicroSDcardhere
18.ResetHole–Usetoresetthedashcamera
1 217181415133456
10
8
16
11
12
9
7
