13. Calibrate “Forced High” (Max Rate) combustion
using switch A (up) and switch B (down). Use the
Gas Pressure Settings on the previous pages for
your model, gas type, and altitude.
14. Move switch 8 of SW1 to OFF.
15. Close hot water taps.
16. Turn off gas supply and 120 V power supply.
17. Remove manometer and re-install screw.
18. Turn on the gas supply and 120 V power supply.
19. Operate the unit and check for gas leaks.
20. Install the front panel using four screws.
Gas Pressure Settings-Indoor
Altitude
Natural Gas Propane Gas
Natural Gas Propane Gas
Short Vent Length (switch #1 on SW1 is ON) Long Vent Length (switch #1 on SW1 is OFF)
Max Rate
inches
W.C.
(mm W.C.)
Min Rate
inches
W.C.
(mm W.C.)
Max Rate
inches
W.C.
(mm W.C.)
Min Rate
inches
W.C.
(mm W.C.)
Max Rate
inches
W.C.
(mm W.C.)
Min Rate
inches
W.C.
(mm W.C.)
Max Rate
inches
W.C.
(mm W.C.)
Min Rate
inches
W.C.
(mm W.C.)
C199i (REU-KBD3237FFUDC-US)
0-2000 ft (0-610 m) 3.1 (79) 0.51 (13) 3.7 (94) 0.52 (13) 3.3 (84) 0.53 (13) 3.9 (99) 0.55 (14)
2001-5200 ft (610-1585 m) 3.0 (76) 0.45 (11) 3.1 (79) 0.45 (11) 3.0 (76) 0.45 (11) 3.1 (79) 0.50 (13)
5201-7700 ft (1585-2277 m) 2.7 (69) 0.40 (10) 2.9 (74) 0.45 (11) 2.7 (69) 0.45 (11) 3.0 (76) 0.45 (11)
7701-10200 ft (2277-3109 m) 2.4 (61) 0.40 (10) 2.0 (51) 0.40 (10) 2.5 (64) 0.40 (10) 2.0 (51) 0.45 (11)
Altitude
Natural Gas Propane Gas
Max Rate
(rythme max) inches
W.C.
(mm W.C.)
Min Rate (rythme
min)
inches W.C.
(mm W.C.)
Max Rate
(rythme max) inches
W.C.
(mm W.C.)
Min Rate (rythme
min)
inches W.C.
(mm W.C.)
C199e (REU-KB3237WDC-US)
0-2000 ft (0-610 m) 3.0 (76) 0.46 (12) 3.5 (89) 0.50 (13)
2001-5200 ft (610-1585 m) 2.9 (74) 0.40 (10) 3.0 (76) 0.45 (11)
5201-7700 ft (1585-2277 m) 2.7 (69) 0.40 (10) 2.8 (71) 0.45 (11)
7701-10200 ft (2277-3109 m) 2.3 (58) 0.40 (10) 2.0 (51) 0.40 (10)
