10 Rinnai Circ-Logic™ with Grundfos Kit
Timer Technical Data
TIMER CONTROL
Supply Voltage: 115-120 VAC, 60 hertz
Ambient Temperature: -4°F to 175°F
Shortest Switching Interval: 15 minute increment
Switch Modes: “Timer”, “ON” Override, “OFF”
Override
Protecon: Clear plasc cover for dust and
moisture protecon of the clock face.
Timer Speed: Default is High and should be
remain at High for Circ-Logic™
Timer Technical Applicaon
The mer control is designed to turn the circulator on
and o at preset mes, allowing the user to select
operaon of the circulator during high use periods of
the day.
The pump will only circulate water when both the
mer and the Circ-Logic™ output are acvated.
Timer Operaon
Seng and operang the mer control and starng the
pump:
NOTE: Before the circulator is started, the system must
be lled with liquid and vented.
1. Set the mer switch to the actual me by turning
the programming ring in the direcon of the arrow
unl the ming arrow points to the actual me on
the ring.
2. Set the required “ON”/”OFF” mes on the
programming ring by pushing the programming
tabs either away from or toward the center of the
ring. Tabs pushed away from the center indicate
the circulator is switched ”ON” while tabs pushed
toward the center indicate the circulator is
switched “OFF”. (See Figure 6B)
3. Set the manual switch to the “TIMER” posion. The
circulator will now start/stop according to the
sengs of the programming tabs.
4. For connuous operaon, set the manual switch to
the “ON” posion. To switch the circulator o, set
the manual switch to the “OFF” posion. The
“ON”/”OFF” modes may be used without aecng
the funcon of either the programming ring or the
mer switch. Note that the circulator is controlled
by both the Timer and the Circ-Logic™ output.
Please see the “Sequence of Operaon” secon for
more details.
5. In case of power outage the mer will not keep
me. Aer power has been restored, the correct
me of day must be reset by rotang the
programming ring in the direcon of the arrow
unl the ming arrow points to the actual me on
the ring.
Programming Ring
Figure 6A
Timing Arrow
Manual Switch
Programming Ring
Programming Tabs
Figure 6B
ON-Tabs pushed
away from center
OFF-Tabs
pushed towards
center
