Rinnai 11 Split AC Wi-Fi OM
MILDEW (FRESH)
Cooling and dehumidifying operations can generate moisture inside the appliance. Using the "FRESH" function
removes such moisture by allowing the fan to run for 3 minutes after every shut-down, avoiding odours and
keeping the unit fresh. Select the Mildew button to enable the Fresh operational mode.
CLEAN BUTTON
Cooling and dehumidifying operations can generate moisture inside the appliance. If the appliance is not going to
be used for a long period (in excess of one month), it is suggested to run the cleaning operation to remove dust
and moisture and avoid odours before leaving. Select the Clean button to start the cleaning operation.
This cleaning operation takes approximately 35mins and the appliance automatically shuts o at
completion of the cleaning cycle.
OPERATION FUNCTIONS
When on this screen, all operational controls (Heating, Cooling, Fan Speed, Set Timer, etc) can be accessed.
MODE BUTTON
This opens the basic operation mode selection tab.
COOLING
When selected this mode operates the Air Conditioner as a cooling appliance
(the available temperature range is 16°C ~ 32°C in 0.5°C increments).
HEATING
When selected this mode operates the Air Conditioner as a heating appliance
(the available temperature range is 16°C ~ 32°C in 0.5°C increments).
FAN
This mode uses the fan to circulate room air without changing the room
temperature.
Adjust Temp up or down
Airflow operation to alter circulation
Select On/Off button, to place the AC
device in Standby mode
Fan Speed (Mute, Low, Mid, High, Turbo, Auto)
Select Mode button, to choose
a basic operation mode
The currently selected AC device’s name
(exit / back) button
Current room temperature
Set temperature
Current operational mode
Select a basic operation
mode or tap on the blank
area to exit tab
Air Conditioner 1
Temperature Ambient 30
0
C
OPERATION
To Next Page
