3.13 External Pump with Circ-Logic
Rinnai SENSEI™ Tankless Water Heaters include Circ-Logic technology that oers the comfort and convenience of
instant hot water with the use of an external recirculaon pump. Circ-Logic controls the on/o sequence and operaon
cycles of the external recirculaon pump through the programming of the tankless water heater’s parameter sengs.
In residenal sengs, the external pump cable is not included with the tankless water heater and must be purchased
separately. Circ-Logic operates in either Economy or Comfort mode based on the parameter sengs of the water
heater.
• Economy Mode—Cycles the pump less oen, using less energy to maintain the circulaon loop temperature.
• Comfort Mode—Cycles the pump more frequently, ensuring the loop temperature remains higher (but also uses
more energy).
Rinnai Set Temperature
140 135 130 125 120 115 110 108 106 104 102 100 98
Typical Pump OFF Intervals (Minutes)
Economy 18 20 22 24 28 32 38 40 44 48 52 56 62
Comfort
9 10 11 12 14 16 19 20 22 24 26 28 31
External Pump
External Pump
Cable
