Rinstrum C520 User Manual

Command = 1000
Data = 12345
2012A408:3E8;
8012A408:0000;
Command = 1000
Data = 0
Status = 0x10 (success)
Command = 0
Data = 0
Status = 0x1 (in progress)
EIP Simple Operation
Result Instance
(read by PLC)
Rincmd
Protocol
EIP Simple Operation
Initiate Instance
(written by PLC)
Command change initiates command and clears result
Rincmd message
sent to C500-K501
Response to command populates result
20.3.4 Rincmd Protocol Object (Class 65
H
)
The following object maps the Rinstrum Rincmd Protocol into the EIP object model. The EIP Instance maps
directly to the Rincmd register ID. The EIP Attribute maps to the Rincmd command as follows:
Instance Attribute
ID
Name Object EIP Ser-
vice
Translates to Rincmd
command
0 (Class) 1 Revision UINT
(value 1)
GAS N/A
Rincmd Register
ID
1 Read Rincmd Integer
Register
DINT GAS 16
H
Read Decimal
Rincmd Register
ID
1 Write Rincmd Integer
Register
DINT SAS 17
H
Write Decimal
Rincmd Register
ID
2 Read Rincmd String Reg-
ister
STRING GAS 16
H
Read Final (String)
Rincmd Register
ID
2 Write Rincmd String Reg-
ister
STRING SAS 17
H
Write Final
(String)
Rincmd Register
ID
3 Read Rincmd Register
Min Value
DINT GAS 02
H
Read Minimum
Rincmd Register
ID
4 Read Rincmd Register
Max Value
DINT GAS 03
H
Read Maximum
Rincmd Register
ID
5 Read Rincmd Register
Type
DINT GAS 01
H
Read Type
Rincmd Register
ID
6 Read Rincmd Register
Permission
DINT GAS 0F
H
Read Permission
The services provided by the Rincmd protocol object are as follows:
Service Code Service Name Class Level Instance Level
0E
H
GAS Yes Yes
01
H
GAA No No
10
H
SAS No Yes
Example: Reading the C500 serial number (rincmd register 0005
H
)
Perform a “Get attribute single” read on class 65
H
, instance 0005
H
, attribute 1 (rincmd register value as
integer). Ethernet/IP GAS C:65
H
/I:0005
H
/A:01
H
will be translated into rincmd: 20160005:;.
Example: Reading the C500 model number (rincmd register 0003
H
)
Perform a “Get attribute single” read on class 65
H
, instance 0003
H
, attribute 2 (rincmd register value as string).
Ethernet/IP GAS C:65
H
/I:0003
H
/A:02
H
will be translated into rincmd: 20160003:;.
Example: Setting setpoint 1 target in the C500 (rincmd register A408
H
)
Perform a “Set attribute single” write on class 65
H
, instance A408
H
, attribute 1 (rincmd register value
112 C500-600-2.0.3
