Device Connections
Wiring Diagram
Rear Line-out(Gray)
ISO Connector
Amplifier
Connector
L(White) R(Red)
Front Line-out(Brown)
L(White) R(Red)
AUX-in
L(White) R(Red)
(Blue)
(Green/ White)
(Pink)
Radio Antenna
Reverse
(Active high level input)
Parking SW
(Active low level input)
Fuse 15A
Video-out 1 Video-out 2
(Yellow) (Yellow)
(Yellow)
Camera-in
(Yellow)
Video-in
Subwoofer out
(Black)
USB slot
