# QTY DESCRIPTION PART #
102 1 LED chevron/outside light monitor circuit board 141579
103 1 LED chevron/outside light monitor circuit
board cover
144835
104 1 Horn, 12VDC, N4X 141573
105 1 Duplex receptacle components 146037
1 Nema 4X Duplex Receptacle components 146485
106 1 Rotary Disconnect Handle 134345
201 1 Pre-drilled control box sub panel 144775
202 1 Power circuit board, Blank 141580
Power circuit board, STR4 or VBR6 fuses
(115 Volt Power)
142126-
02
Power circuit board, STR4 or VBR6 fuses
(230 Volt Power)
142126-
03
Power circuit board, All other restraints
(115 Volt Power)
142126-
04
Power circuit board, All other restraints
(230 Volt Power)
142126-
05
203 1 Micro Control Board with Program Options
(Consult Rite‑Hite for specic part number)
141578-
xxx
204 1 Micro circuit board cover 146551
205 1 Control wiring harness, P1 enclosure 144864-
01
Control wiring harness, P1 enclosure with
emergency stop button
147333-
01
Control wiring harness, P2 enclosure 144864-
02
Control wiring harness, P2 enclosure with
emergency stop button
147333-
02
206 1 Dok-Commander option board 143134
207 1 Leveler option board 143135
209 1 Ribbon Cable, Micro Control Board to
Dok-Commander option board
156203
210 1 Magnetic ferrite lter 146324
211 1 Ribbon Cable, Dok-Commander option board
to leveler option board
142419
212 1 Incoming power terminal block assembly
(115V or 230V/1PH/50Hz incoming power)
144867
Incoming power terminal block assembly
(230V/1PH/60Hz incoming power)
146032
Incoming power terminal block assembly
(3PH incoming power)
144869
Incoming power terminal block assembly,
rotary disconnect
(115V or 230V/1PH/50Hz incoming power)
144760
Incoming power terminal block assembly,
rotary disconnect
(230V/1PH/60Hz incoming power)
146033
Incoming power terminal block assembly,
rotary disconnect (3PH incoming power)
144871
213 1 Rotary disconnect shaft 6mm x 6mm 134346
214 1 Incoming power decal with rotary disconnect 108765
Incoming power decal without rotary disconnect 122529
215 1 Motor Contactor, 1PH, Hydra-Rite 144879
Motor Contactor, 1PH, 144540
Motor Contactor, 3PH 144541
216 1 Motor Overload Relay, Hicap 145118
Motor Overload Relay 127199
# QTY DESCRIPTION PART #
217 1 Transformer, 500VA, 230/460V 146025
Transformer, 500VA, 575V 146026
Transformer, 1000VA, 230/460V 146027
Transformer, 1000VA, 575V 146028
Transformer, 2000VA, 230/460V 146029
Transformer, 2000VA, 575V 146030
218 2 Ground Lug 55902
219 2 Ground Lug Decal 54069
220 2 Ground Symbol Decal 105454
221 1 Fuse Cover, 5mm x 20mm 144544
222 1 Fuse Cover, 5mm x 20mm 144544
223 1 Fuse Cover, 5mm x 20mm 144544
224 1 Fuse Cover, 5mm x 20mm 144544
225 1 Terminal Label panel decal 146324
301 1 Enclosure with decals (consult Rite-Hite for
specic part number)
852.xxx
Enclosure Mounting Feet, Includes 4 Feet
[Not needed if ordering new enclosure]
147845
307 1 Cover decal 16 x 14, P1 enclosure 141500
Cover decal 16 x 14, P1 enclosure with Lok-Vu 150910
Cover decal 18 x 16, P2 enclosure 144734
Cover decal 18 x 16, P2 enclosure with Lok-Vu 150911
308 1 DOK-LOK inlay decal, Manual Restraint, 3
button horn override
144806
DOK-LOK inlay decal, LTCM, 3 button horn
override
145907
DOK-LOK inlay decal, 3 button horn override
(Less Advanced Control Package)
144803
DOK-LOK inlay decal, MWL, 4 button coded
horn override
144804
DOK-LOK inlay decal, GWL, 5 button coded
horn override (Advanced Control Package)
144805
DOK-LOK inlay decal, 5 button coded horn
override (Advanced Control Package)
141502
309 1 Leveler inlay decal, Pit leveler 144807
Leveler inlay decal, Pit leveler, Dock light 144809
Leveler inlay decal, Pit leveler, Overhead
door control
144808
Leveler inlay decal, Pit leveler, Dock light,
Overhead door control
144810
Leveler inlay decal, Pit leveler, IFC 144811
Leveler inlay decal, Pit leveler, IFC, Dock light 144813
Leveler inlay decal, Pit leveler, IFC,
Overhead door control
144812
Leveler inlay decal, Pit leveler, IFC, Dock
light, Overhead door control
141503
Leveler inlay decal, Pit leveler, IFC, Lower
button
144815
Leveler inlay decal, Pit leveler, IFC, Lower
button, Dock light
144817
Leveler inlay decal, Pit leveler, IFC, Lower
button, Overhead door control
144816
Leveler inlay decal, Pit leveler, IFC, Lower
button, Dock light, Overhead Door control
144818
Leveler inlay decal, Vertical leveler 144819
Leveler inlay decal, Vertical leveler, Dock light 144821
Leveler inlay decal, Vertical leveler, Overhead
door control
144820
Leveler inlay decal, Vertical leveler, Dock
light, Overhead door control
144822
310 1 Rotary disconnect overlay decal 144823
PARTS
Dok-Commander Continued
