Installation/Service/Owner's Manual Dok‑Commander
®
Publication: AMEN00070 2020-01-30 33
# QTY DESCRIPTION PART #
311 1 Emergency stop overlay decal 144824
Platform stop overlay decal 144825
312 1 Keyed horn override overlay decal 144828
Keyed power overlay decal 144826
Keyed unlock overlay decal 144827
313* 1 Unidox overlay decal 146035
314 1 Operation/danger/warning decal for Pit
leveler
144844
Operation/danger/warning decal for Pit
leveler, IFC
144846
Operation/danger/warning decal for Pit
leveler, IFC, Lower button
144847
Operation/danger/warning decal for Vertical
leveler
144848
315 1 Danger/warning decal for MWL 144886
Danger/warning decal for GWL 144843
Danger/warning decal for Vertical barrier
restraints
144842
Danger/warning decal for Shadow Hook
restraints
144774
316 1 Lockout/tagout/multiple disconnect warning
decal
114331
317 1 Duplex receptacle rating decal, 5 Amp 147456
Duplex receptacle rating decal, 15 Amp 147457
501 1 15A fuse, 0.25" x 1.25" (STR4 or VBR6
restraint with 60Hz power)
57864
7.5A fuse, 0.25" x 1.25" (STR4 or VBR6
restraint with 50Hz power)
145215
5A fuse, 0.25" x 1.25" (SHR5, VBR3,
GWL23, LTCM and manual restraints with
60Hz power)
57419
2.5A fuse, 0.25" x 1.25" (SHR5, VBR3,
GWL23, LTCM and manual restraint with
50Hz power)
126964
502 1 1A fuse, 5mm x 20mm (115V control box) 142092
0.5A fuse, 5mm x 20mm (230V control box) 145216
503 1 0.5A fuse, 5mm x 20mm 145216
504 1 0.5A fuse, 5mm x 20mm 145216
505 1 2A fuse, 5mm x 20mm (Incandescent dock
light with 60Hz power)
142353
1A fuse, 5mm x 20mm (Incandescent dock
light with 50Hz power)
142092
0.5A fuse, 5mm x 20mm (LED dock light) 145216
506 1 30A fuse, CC, Dual element time delay (115V
incoming power)
103233
15A fuse, CC, Dual element time delay
(230V/1PH/50Hz incoming power)
108703
2 15A fuse, CC, Dual element time delay
(230V/1PH/60Hz incoming power)
108703
25A fuse, CC, Dual element time delay
(230V/60Hz incoming power and Hydra-Rite
leveler)
102236
3 3A fuse, CC, Dual element time delay (575V
incoming power)
103100
6A fuse, CC, Dual element time delay (460V
or 380-415V incoming power)
103234
10A fuse, CC, Dual element time delay
(230V/3PH incoming power)
103229
# QTY DESCRIPTION PART #
507 2 2A fuse, CC, Dual element time delay (500VA
transformer and 575V incoming power)
66019
2.5A fuse, CC, Dual element time delay (500VA
transformer and 460V incoming power)
147631
3A fuse, CC, Dual element time delay (500VA
transformer and 380-415V incoming power)
66007
4A fuse, CC, Dual element time delay
(1000VA transformer and 460V or 575V
incoming power)
65241
5A fuse, CC, Dual element time delay
(1000VA transformer and 380-415V incoming
power)
66008
5A fuse, CC, Dual element time delay (500VA
transformer and 230V incoming power)
66008
7A fuse, CC, Dual element time delay
(2000VA transformer and 575V incoming
power)
66010
8A fuse, CC, Dual element time delay
(1000VA transformer and 230V/60Hz/50Hz
incoming power)
65988
10A fuse, CC, Dual element time delay
(2000VA transformer and 380-415V incoming
power)
66012
15A fuse, CC, Dual element time delay
(2000VA transformer and 230V/60Hz/50Hz
incoming power)
65895
508 1 3A fuse, CC, Dual element time delay (115V
or 230V/50Hz and OHD power <2A)
103100
6A fuse, CC, Dual element time delay (115V
or 230V/50Hz and OHD power >2A and <4A)
103234
10A fuse, CC, Dual element time delay (115V
or 230V/50Hz and OHD power >4A and <6A)
103229
15A fuse, CC, Dual element time delay (115V
or 230V/50Hz and OHD power >6A and
<10A)
108703
25A fuse, CC, Dual element time delay (115V
or 230V/50Hz and OHD power >10A)
102236
2 3A fuse, CC, Dual element time delay
(230V/1PH/50Hz and OHD power <2A)
103100
6A fuse, CC, Dual element time delay
(230V/1PH/50Hz and OHD power >2A and
<4A)
103234
10A fuse, CC, Dual element time delay
(230V/1PH/50Hz and OHD power >4A and
<6A)
103229
15A fuse, CC, Dual element time delay
(230V/1PH/50Hz and OHD power >6A)
108703
3 3A fuse, CC, Dual element time delay (3PH and
OHD power >0A and <2A)
103100
6A fuse, CC, Dual element time delay (3PH
and OHD power >2A and <4A)
103234
10A fuse, CC, Dual element time delay (3PH
and OHD power >4A)
103229
509 1 15A circuit breaker (15A receptacle) 109188
5A circuit breaker (5A receptacle) 136167
510 1 15A circuit breaker, din rail (60Hz Unidox
power)
66020
5A circuit breaker, din rail (50Hz Unidox
power)
127899
601 1 Mushroom push button (if equipped) 125163
602 1 Selector Switch, keyed (if equipped) 125194
603* 1 Unidox component assembly 146002
Unidox component assembly with overload 146044
PARTS
Dok-Commander Continued
