Page #34 background imageLoading...
Page #34 background image
Dok‑Commander
®
Installation/Service/Owner's Manual Rite‑Hite
®
34 Publication: AMEN00070 2020-01-30
PARTS
Dok-Commander Continued
# QTY DESCRIPTION PART #
604 1 Overhead door power component assembly,
115V/1PH or 230V/1PH/50Hz
146003
Overhead door power component assembly,
230V/1PH/60Hz
146036
Overhead door power component assembly,
3PH
146004
605 1 MWL lock actuator component assembly 146005
606 1 Photoeye interconnect component assembly 150419
607 1 Lok-Vu enclosure component assembly 149538
608 1 Opti-Vu circuit board 159000
701 6 Stando󰀨, Male/Female, #6‑32, 0.75" length 142100
702 6 Stando󰀨, Male/Female, #6‑32, 1.625" length 142101
703 6 Screw, round head, #6-32, 0.25" length 133366
704 6 Lock washer, #6 51826
705 7 Stando󰀨, Male/Female, #6‑32, 0.75" length 142100
706 4 Stando󰀨, Male/Female, #6‑32, 1.625" length 142101
707 7 Screw, round head, #6-32, 0.25" length 133366
708 7 Lock washer, #6 51826
709 2 Screw, slotted, #8-32, 0.5" length 51645
710 2 Lock washer 51760
711 2 Screw, slotted, #8-32, 0.5" length 51645
712 2 Lock washer 51760
713 4 Screw, #1/4-20, 0.5" length 103230
Screw, #5/16-18, 0.75" length 146080
714 4 Lock washer, 0.25" 51800
Lock washer, #5/16 51803
715 4 Rubber Grommet 142102
716 4 Screw, #8, 0.5" length, washer 146031
717 4 Stando󰀨, Male/Female, #6‑32, 0.875" length 115871
718 1 Screw, slotted, #8-32, 0.5" length 51645
719 1 Lock washer 51760
720 4 Screw, round head, #10-32, 0.5" length, 51629
721 4 Lock Washer, #10 51762
722 2 Screw, Philips, M4, 12mm length 147382
*Not Shown
