10
STEP 4
ASSEMBLY AND ADJUSTMENT
Cross Frame
M10x70 Square Neck Bolt
NO. DESCRIPTION
QUANTITY
1
4
9
b
M10 Washer
M10 Nut
4
4
g
h
9
b
h
g
b
h
g
