12
STEP 6
ASSEMBLY AND ADJUSTMENT
Weight Plate Rack
M10x20 Hex Bolt
1
NO. DESCRIPTION
QUANTITY
2
8
d
M10 Washer
2h
d
h
8
d
h
NOTE: Pre-installed, inside the Cable.NOTE: Pre-installed, inside the Weight Plate Rack.
