ASSEMBLY
M10x70 Square Neck Bolt
2
STEP 2
9
Plate Holder Frame
4
a
f M10 Nut
4
h M10 Washer
4
NO. DESCRIPTION QUANTITY
a
h
f
9
2x
9
