Ritmo BASIC 200 V0 - Page 20

3. PARTS DESCRIPTION ﻊﻄﻘﻟا ﻒﺻو
3./2
ةاﻮﺴﻤﻟا
1. ﺔﻗﺎﻄﻟا داﺪﻣإ ﻞﺒآ
2. ﺪﻴﻟا ﺾﺒﻘﻣ
3. كﺮﺤﻤﻟا
4. ﻲﻃﺎﻐﻀﻧﻻا ءﺪﺒﻟا رز- ﺮﻀﺧأ)كﺮﺤﻣ(
5. ﻲﻃﺎﻐﻀﻧﻻا فﺎﻘﻳﻹا رز- ﺮﻤﺣأ)كﺮﺤﻣ(
6. ﻊﻧﺎﻤﻟا عارﺬﻟا
7. ﻲﻃﺎﻐﻀﻧﻻا ةﺮﺋاﺪﻟا ﻊﻃﺎﻗ رز
8. سﺎﺒﻜﻟا ﺐﻴﻀﻗ ﺔﻣﺎﻋد ﺔآﻮﺷ
9. ةﺮﻔﺸﻟا
10. ةاﻮﺴﻤﻟا صﺮﻗ
FACER
11. Power supply cable
12. Handgrip
13. Motor
14. Start push button - green (motor)
15. Stop push button - red (motor)
16. Blocking lever
17. Circuit breaker push button
18. Fork for piston rod support
19. Blade
20. Facer disk
