HOW TO STEAM
BURN HAZARD.
Steam is hot. Always make sure unit is OFF when assembling attachments.
w WARNING
Fill with cool water UP TO MAX FILL
LINE ONLY using the fill/drain hole.
NEVER use fabric fresheners or other
additives in the steamer.
The float ball will rise to the top of
the tank when it reaches full capacity.
IMPORTANT: Maximum capacity is 1
liter or 34 ounces. DO NOT OVERFILL.
4
3
NOTE: The fixed vent opening in the
cover allows excess steam to escape.
Position door hook over top of a
door.
6
5
Elevate spray nozzle by hanging on
door hook. This avoids pooling of
condensation in hose.
NOTE: Always elevate steam nozzle
during heat-up and use.
Plug unit into electrical outlet.
WARNING! Burn Hazard: Always
place steamer on the floor during
use. Hot water can leak from the
steamer if tipped over.
