STEP 5
STEP 5
9
Tighten Mounts
5
Remove from vehicle and rotate the entire Quick
Release Mount clockwise until secure and parallel with
the extrusion. Ensure each mount aligns with marks
made previously. Repeat for each mount.
• DO NOT OVERTIGHTEN OR DAMAGE
MAY OCCUR
!
ROTATE CLOCKWISE TO TIGHTEN
(view shown from underside)
CORRECT SECURE ALIGNMENT
