RJM Music Technology, Inc.
www.rjmmusic.com
Rack Gizmo Wiring Diagram
Rack Gizmo Wiring Diagram
6 pedals in front of two amps
The guitar signal passes from the front panel jack, through the buer, then through the
rst 6 audio loops, through the Click Stopper circuit.
The last two loops are used to select between two amps. You can turn on either amp,
both amps, or none (for silent tuning). Loop 7 enables amp 1, Loop 8 enables amp 2.
You may need to use an isolation transformer on the second amp (marked Iso on
the diagram), but try the conguration without it rst.
The Rack Gizmo controls channel switching on both amps using the function
switching jacks.
Guitar connects to front panel input
Iso
