RKI Instruments CO-01 - Description

01Series Operator’s Manual Description • 4
Description
This section describes the components of the 01 Series. These
components include the 01 Series’ protective rubber boots, case,
membrane retainer and filter disks, sensor retainer, sensor, LCD, control
buttons, printed circuit boards, alarm lights, buzzer, vibrator, and batteries.
LCD
Control Buttons
Alarm Lights
Buzzer Opening
Membrane
Retainer
Sensor
Retainer
Battery Cover
Battery Charging
Contacts
POWER
MODE
AIR
CO-01
CO
Sensor En
d
Boot
Battery End
Boot
Threaded
Inserts
Figure 1: Components of the 01 Series
