GENERAL INFORMATION
Translation of the original instructions
14
2.2 User information, RAEE Directive on waste electrical and
electronic equipment
With regard to the regulatory framework of reference of the European Community, we remind the user of the
following:

· Used AAE (Electrical and Electronic Equipment) products must be collected separately
· The user can carry out this collection in the RAEE collection systems and return the equipment to the
distributor when purchasing a new one
· Plus being RoHS compatible, (in accordance with Directive 2011/65/EU on the restriction of the use of
certain hazardous substances in electrical and electronic equipment) the potential effects on the
environment and human health may be due to the misuse of the same equipment or parts of it
· The symbol next to the rating plate indicates the obligation of separate collection
· The penalties provided for in the event of improper disposal of RAEE (Waste Electrical and Electronic
Equipment) are those provided for by the national transpositions of European Directives 2012/19/EU
2.3 Technical data table
Electrical technical data table CP S70E
MODEL DIMENSIONS POWER SUPPLY
MAXIMUM
POWER (kW)
MAXIMUM INPUT
(A)
Silicon POWER
SUPPLY CABLE
CPT-74ET 40x70x29h 400V~3N 50/60 Hz 4,15 6 5 x 1 mm²
CPT-76ET 60x70x29h 400V~3N 50/60 Hz 6,25 9,02 5 x 1,5 mm²
CP-74ET 40x70x90h 400V~3N 50/60 Hz 7,8 11,3 5 x 1,5 mm²
CP-76ET 60x70x90h 400V~3N 50/60 Hz 13,5 19,48 5 x 2,5 mm²
CP-78ET 80x70x90h 400V~3N 50/60 Hz 15,6 22,61 5 x 2,5 mm²
CPA-74ET 40x70x90h 400V~3N 50/60 Hz 7,8 11,3 5 x 1,5 mm²
CPA-76ET 60x70x90h 400V~3N 50/60 Hz 13,5 19,48 5 x 2,5 mm²
CPA-78ET 80x70x90h 400V~3N 50/60 Hz 15,6 22,61 5 x 2,5 mm²

Transformation
MODEL DIMENSIONS POWER SUPPLY
MAXIMUM
POWER (kW)
MAXIMUM INPUT
(A)
Silicon POWER
SUPPLY CABLE
CPT-74ET 40x70x29h 230V~ 50/60 Hz 4,15 18,04 3 x 2,5 mm²

