503.20 p.17
item
no. designation quant. W material part no.
1000 switch rod, optionally for:
1000 RMG 711 DN 25 and DN 50 1 NSt 10 022 568
1000 RMG 503 DN 25/50 and DN50/100 1 NSt 10 022 568
1000 RMG 530 DN 50/100 1 NSt 10 022 568
1000 RMG 711 DN 80 and DN 100 1 NSt 10 022 573
1000 RMG 503 and RMG 530 DN 80/150 and DN 100/200 1 NSt 10 022 573
1000 RMG 711 DN 150 1 NSt 10 022 578
1001 threaded bolt 1 St 00 008 486
1002 connection flange 1 LM 10 022 582
1003 guiding screw 1 NSt 10 001 811
1004 pressure spring 1 SF 10 001 183
1005 hexagonal nut 1 St 00 003 020
1006 adjustment nut 1 Ms 10 001 864
1007 bushing 1 LM 10 022 584
1008 O ring 1 KG 00 020 327
1009 magnet 1 00 024 436
1010 threaded bolt 4 NSt 10 022 585
1011 cover 1 LM 10 022 583
1012 packing ring 1 LM 00 018 706
1013 screw plug 1 St 00 026 523
1014 locking washer 4 SF 00 014 113
1015 hexagonal nut 4 St 00 005 692
1016 pressure spring 1 SF 00 028 067
1017 screw plug 1 Ms 10 022 586
1020 proximity switch 1 00 024 160
1021 cable box 1 00 024 099
1022 relay, optional:
1022 for 1 proximity switch (230V AC) 1 00 024 402
1022 for 2 proximity swirtches (230V AC) 1 00 024 403
3.3.4 Spare part list accessories
