RMG 503 - Spare Parts List

item
no. description quant W material DN 25/50 DN 50/100 DN 80/150 DN 100/200
RMG stock no.
1 body, version "-":
1 PN 40 1 GS 10 024 470 10 024 520 10 024 620
1 PN 40 / ANSI 600 RF 1 GS 10 024 477 10 024 527 10 024 627
1 ANSI 300 RF 1 GS 10 024 473 10 024 523 10 024 623
1 ANSI 300 RF / ANSI 600 RF 1 GS 10 024 478 10 024 528 10 024 628
1 ANSI 300 RJ 1 GS 10 024 474 10 024 524 10 024 624
1 ANSI 600 RF 1 GS 10 024 475 10 024 525 10 024 625
1 ANSI 600 RJ 1 GS 10 024 476 10 024 526 10 024 626
1body, version "a"
1 PN 40 1 GS 10 027 670
1 PN 40 / ANSI 600 RF 1 GS 10 027 677
1 ANSI 300 RF 1 GS 10 027 673
1 ANSI 300 RF / ANSI 600 RF 1 GS 10 027 678
1 ANSI 300 RJ 1 GS 10 027 674
1 ANSI 600 RF 1 GS 10 027 675
1 ANSI 600 RJ 1 GS 10 027 676
4 screw plug 3 St 00 026 175 00 026 175 00 026 175 00 026 175
5sealing ring 6 LM 00 018 842 00 018 842
5 sealing ring 5 LM 00 018 842 00 018 842
6 connecting piece 1 St 00 030 074 00 030 074 00 030 111 00 030 111
7 connecting piece 1 St 00 030 111 00 030 111 00 030 023 00 030 023
8 connecting piece 1 St 00 030 074 00 030 074 00 030 074 00 030 074
503.20 p.07
2.3.2. spare parts list
WParts should be kept in stock for maintenance purposes
material identifications
St ... steel LM ... light alloy SSt ... foam
NSt ... rustproof steel Ms ... brass K ... plastic
FSt ... spring steel Cu ... copper KG ... rubbery plastic
NFSt ... rustproof spring steel Bz ... bronze KGT ... rubbery plastic with coating
GS ... steel cast GLM ... light alloy cast KV ... rubber-like plastic material (NBR)
GGG ... steel cast with spheroidal graphite GMs ... brass cast KT ... special plastic (NBR)
GZn ... zink cast AlBz ... aluminium bronze PGL ... plexiglass
GBz ... bronze cast
