DINETTE TABLE:
The table leg is stored in the closet in the Versatile (see Picture B-P4), or in the upper passenger side shelf in the
Popular. Remove the table leg and place it into the floor base receptacle located in the rear seating area.
The table top is stored under the driver side rear bed cushion in the dinette models, (see Picture B-P6 and B-P8). Place
the table top on top of the table leg, (see Picture B-P5 and B-P7). In the units with the optional power sofa, the dinette
table is located at the rear of the galley.
When returning table top to the storage position ensure the table base is placed correctly in the table base
receptacle located on top of the rear driver side bench, (see Picture B-P6 and B-P8). Return the table leg to the
front wardrobe closet and clip into place for proper storage.
Picture B-P6: Storage location of dinette table,
showing placement of the table base receptacle,
(Popular model with dinette).
Picture B-P5: Location of assembled dinette table,
(Popular model with dinette).
Picture B-P7: Location of assembled dinette table,
(Versatile model with dinette).
Picture B-P8: Storage location of dinette table,
showing placement of the table base receptacle,
(Versatile model with dinette).
