Installation instruction
Selection of installation equipment
Cut out the work surface according to the sizes shown in the drawing.
For the purpose of installation and use, a minimum of 5 cm space shall be preserved
around the hole.Be sure the thickness of the work surface is at least 30mm. Please
select heat-resistant work surface material to avoid larger deformation caused by the
heat radiation from the from the hotplate. As shown below:
Under any circumstances, make sure the Induction cooker hob is well ventilated and
the air inlet and outlet are not blocked. Ensure the Induction cooker hob is in good
work state. As shown below
Note: The safety distance between the hotplate and the cupboard above the
hotplate should be at least 760mm.
