1.Surface maintenance: Please clean the surface of stove with neutral detergent and then wipe it with dry
cloth. Do not clean the surface with wire brush or other hard objects.
2.In order to maintain the normal operation and good combustion status of the stove, brush and steel needle
must be used regularly to unblock the flame outlet (groove) and remove the dirt on burners, so that stove
damages by flareback due to blocked flame outlet (groove) can be avoided. Do not wash the flame outlet (groove)
with water.
3.Check the cap and their seats regularlyfor any displacement or deviation and carry out
rectification accordingly (to put them in place), so as to avoid the occurrence of accident.
(The figure is provided for reference only and subject to the actual product.)
◆IMPORTANT In order to ensure the stability and safety of the pan, please do not use the pan less
than 100mm size, and when using a 100mm size pan cooking must first placed the auxiliary pot rack
on the pot rack.
◆Warning: Wok ring can be used on wok burner only
:
.
Auxiliary pot rack
Pot rack
Internal cap
External cap
Copper base
Drain pan
Drain pan apron
Knob
Panel positioning board
Waterproof ring
Sponge strip
Panel
Burner rubber mat
Electrode needle
Spring piece
Thermocouple
Electrode needle
Injector
Burner
Injector
Burner bracket
Aluminum tube
Intake pipe
Power cable
Pot rack
Cap
Copper aluminum base
Drain pan
Guard ring
Sponge strip
Burner rubber mat
Thermocouple
Screw
spring
Thermocouple
Electrode needle
Injector
Burner
Burner bracket
Aluminum tube
Aluminum tube
Aluminum tube
Valve body
Valve body
Chassis
Ignition unit
11
Gas Hob
