◆This includes situations where appliance have been tiled in, sealed in with sealant, have wooden obstructions
placed in front of the appliance, like plinths, or any installation other than the one specified by
ROBAM APPLIANCES CO.,LTD. has been completed.
◆IMPORTANT:ROBAM APPLIANCES CO.,LTD.operates a policy of continuous improvement and reserves
the right to adjust and modify its products without prior notification.
Before first use
YOU SHOULD CLEAN THE HOB SURFACE(SEE“CLEANING AND MAINTENANCE” SECTION).
The following symbols will appear on the control panel,
next to each control knob:
: Gas Off
: Maximum Setting
: Minimum Setting
Operation Methods
“ ”
“ ”
“ ”
To ignite a burner:
◆
◆
◆Never select a knob position between the maximum and off position.
◆The symbol on the control panel, next to the control knob will indicate which gas burner it operates.Automatic
ignition with flame failure safety device, the appliance is fitted with a flame failure safety device on each burner,
which is designed to stop the flow of gas to the burner head in the event of the flame going out.
◆When the push button is ignited, only the inner ring ignites, and the outer ring is ignited after the hand is released.
The minimum setting is at the end of the anti-clockwise rotation of the control knob.
All operation positions must be selected between the maximum and minimum position.
◆Check if the burner, cap, or other parts are positioned correctly, and confirm the knob
button(Picture 1) position, then turn on the gas valve.
◆If you keep the control knob depressed, the automatic ignition for the burner will operate.
◆Ignition:Press the control button then contrarotate 90 degree accordingly, it's Large flame.You should hold
down the control knob for 15 seconds after the flame on the burner has lit. If after 15s the burner has not lit,
stop operating the device and open the compartment door and wait at least 1 min before attempting a further
ignition of the burner.
◆After this 15-second interval, to regulate the flame you should continue turning the control knob anti-clockwise
until the flame is at a suitable level. The operating position must be at a position between the maximum position
(Picture 2)and minimum position(Picture 3).
◆To switch the burner off, turn the control knob fully clockwise to the gas off position.
◆Extinguish: the burner will be extinguished when the knob turn to(Picture1) the position.
◆The use-method of hob at low temperature is the same as in normal temperature.
Energy saving tips
Pan Size
Burners
Ø min Ø max
WOK
Semi-Rapid
260mm 280mm
◆
◆Use flat bottomed pans only.
◆When possible, keep a lid on the pan whilst cooking.
◆Cook vegetables with as little water as possible, to reduce cooking times.
The burner flame must never extend beyond the diametre of the pan.
160mm 200mm
IMPORTANT: Always place pans centrally over the hob burners and position them so, You should also
make sure that the handle is not over one of the other hob burner flames.
9
