Circuit Diagram
Note: The supply connection point shall be accessible with the appliance installed.
IGNITION UNIT
220-240V 50/60Hz
TO ELECTRODES
TO ELECTRODES
TO ELECTRODES
SWITCH HARNESS
SWITCH HARNESS
SWITCH HARNESS
Thermocouple
Thermocouple
Thermocouple
E
N
L
13
Gas Hob
