4-4- 14 CONTACT BREAKER (POINT)
CAPACITOR (EC06)
Install the contact breaker by inserting'its shaft into
the matching hole in the rcrankcase. Pass the cord
under the capacitor into the cord hole in the crank-
case.
Temporarily tighten the capacitor.
4-4- 15 IGNITION TIMING CHECK (EC06)
Temporarily install the flywheel, and check and ad-
just the ignition timing.
(For ignition timing adjustment, refer to the section
on contact breaker adjusting procedure.)
Note: Ignition timing ............... 23" k2'
4-4- 16 POINT COVER (EC06) , ,'
Remove the flywheel, fit the point-to-capacitor lead
into the crankcase groove, and install the.point cov-
er. (See Fig. 14.)
Tighten the temporarily tightened capacitor securely.
Note: Tightening torque ......... 25 f 2 kg-cm
Lead Wiring Method
Crankcase Groove
II -./ I
//
Capacitor Lead
Primary Wire
Turn primary wire once and
w
pull it in direction A.
I
I
Capacitor lead is above
primary wire here.
Fig. 14
4-4- 17 FLYWHEEL (MAGNETO)'
Install the flywheel on the crankshaft by tightening
the nut'with plain and spring washers.
Note: Completely remove oil from the tapered por-
tion.
Tightening torque
....... 400 k 20 kg-cm
4-4- 18 IGNITION COIL
Adjust the air gap with a searcher, and tighten the
ignition coil with plain and spring washers. (See Fig.
15.)
Note: Air gap. .... .0.5 foe. mm
Tightening torque
.......... 50 f5 kg-cm
Fig.
15
4-4-,19 STARTER PULLEY
Tighten the starter pulley
to the flywheel with the
bolt. (Use plain and spring washers.)
Note: Tightening torque ........ 90 f IO kg-cm
4-4-20 FAN COVER, STOP BUTTON,
GROMMET (See Figs. 16 and
17.)
Install the stop button with lockwasher on the fan
cover. Insert the high-tension cord into the grom-
met, and install baffle rubber on the fan cover. Fit
the grommet into the fan cover groove and, with the
tip
of the rubber baffle at the round boss in the
crankcase, fasten the fan cover on the crankcase
with the bolt.
Note: Be careful not to pinch the stop button cord
between the crankcase and
fan cover. Also exercise
care not to drop the rubber baffle during fan cover
reassembly.
.L
Tightening torque ........ 90 2 10 kg-cm
-11 -
