3. PRE-OPERATION CHECKS
-
7
-
CHECK ENGINE OIL
Before checking or refilling engine oil, be
sure the engine is located on a stable, level
surface and stopped.
■
Do not thread the gauge into oil filler to
check oil level.
■
If the oil level is below the lower level
line on the dipstick, refill with the proper
oil (see table) up to the upper level (up to
the point of overflowing the filler neck).
■
(EH035V) Before filling oil, make sure that
the oil drain screw is secured thoroughly.
■
Change oil if it is contaminated.
(See page 11 Maintenance Schedule.)
■
Use class SF (API classification) or
higher grade oil.
■
If multi-grade oil is employed, oil
consumption tends to increase when
the ambient temperature is high.
■
Wipe off any spilled oil before starting
the engine.
Lower level
Upper level
Oil gauge
5W
10W
20W
#20
#30
#40
10W-30
10W-40
Single
grade
Multi
grade
Ambient
temperature
-20 -10 0 10 20 30
40
-4 14 32 50 68 86
104
■
Stop the engine and open the cap.
■
Incline the engine as fuel inlet upward,
then refill fuel to the upper level. Do
not fill fuel too much.
■
Use automotive unleaded gasoline only.
This engine is 4-stroke gasoline engine.
■
When filling the fuel tank, always use
the fuel filter.
■
Wipe off any spilled fuel before starting
the engine.
CHECK FUEL
CAUTION
Do not refuel while smoking,
near an
open flame or other
potential hazards.
NOTE :
THIS ENGINE IS CERTIFIED TO OPERATE
ON AUTOMOTIVE UNLEADED GASOLINE.
EH025 . . . . . . . . . . . . . . . . . . 80
EH035/035V. . . . . . . . . . . . . . 100
Oil capacity (Upper level) : (mL)
EH035Vus_EU2308 06.12.22 10:07 AM ページ7
