10. SPECIFICATIONS
− 21−
MODEL EH63D EH64D EH65D
Type
Air-Cooled, 4-Stroke, V-Twin Cylinder, Horizontal P.T.O. shaft,
OHV Gasoline Engine
Bore x stroke 2-3.15 in x 2.56 in (80 mm x 65 mm)
Displacement 39.8 cu in. (653 cm
3
)
Continuous Output
kW (HP) / rpm
10.8 (14.5) / 3600 11.9 (16.0) / 3600 12.7 (17.0) / 3600
Max.Torque N・m (kgf・m)/ rpm
43.3 (4.41) / 2000 44.4 (4.52) / 2200 45.6 (4.65) / 2500
Direction of Rotation Counterclockwise as viewed from P.T.O. shaft side
Lubricant
Automobile Engine Oil SAE #20, #30 or 10W-30 ;
Class SE or higher
Capacity of Lubricant 52.48 oz. (1.55 liter)
Fuel Automotive Unleaded Gasoline
Spark plug NGK BP6ES
Starting System Electric Starter
Dry Weight 97.0 lb. (44 kg)
Dimension (L x W x H) 12.5 in x 18.8 in x 18.7 in (317 mm x 477 mm x 475 mm)
13.4 (18.0) / 3600 15.3 (20.5) / 3600 16.4 (22.0) / 3600
Maximum Output
kW (HP) / rpm
Valve Clearance
(Intake & Exhaust)
0.0039 ± 0.0008 in (0.1 ± 0.02 mm)
Note : Adjust the valve clearance while the engine is cold.
Emissions Durability Period
(California only)
500 hours
