FULL POWER SWITCH (Except RGV2800)
Select the voltage using the FULL
POWER SWITCH in accordance
with the electrical appliance.
Refer to
TABLE 2.
120V 120V
240V
Change the FULL POWER SWITCH
after turning the no-fuse breaker
to "OFF".
［
CAUTION
］
NOTE :
Voltmeter always indicates the lower voltage whichever the FULL POWER
SWITCH is set.
TABLE 2
Switch position Lower Voltage Receptacle Higher Voltage Receptacle
120V Activated full rated output N.A
120/240V Activated half of rated output Activated full rated output
