SmartPAT 5500
Storage format
Set floppy storage
format ? YES/NO
Press YES to perform this function.
Use UP/DOWN then GO
Format: Print
Use the UP/DOWN controls to select the storage format required. The selection is:
Print Robin.txt = Text document
PC database Robin.csv = Comma separated variable file
PowerPAT Plus Robin.rob = PowerPAT Plus document
Industry Std Robin.ind = Industrial file
Note: If you are using Robin PowerPAT Plus software or Robin PATEST 5000 software select
“PowerPAT Plus”
On completion press GO, the following is displayed to confirm the selection as been set:
Format: Print
Press STOP to return to main menu
Professional/Normal
The Tester can be selected for operation in the Professional or Normal mode.
In the Professional mode the messages displayed to the user during the test sessions are reduced along
with the test duration times. This allows a user who is familiar with the test sequences and the actions
the test performs to reduce the testing time and increase the speed of work.
In the Normal mode all messages are displayed and the tester guides the user through each individual
action. It is recommended that Normal mode is selected until the user is fully practised in using the
tester and understands the functions of each test,
Professional Mode is only for experienced and competent users.
Set up Professional/
Normal mode ? YES/NO
Press YES to perform this function.
Enter access code
….
Enter access code, then press GO, the following is displayed:
Code accepted
After a few seconds the following screen is displayed:
YES for Professional
or NO for Normal
22
