Robomow RC306 Original Operating Instructions

45
EN
Code Descripon Correcve Acon
09
One-Time setup is running
One-Time setup should be completed before the
automatic operation can start
11
Automatic operation is disabled by menu P021
(see Section 6.4.2)
Enable automatic operation through menu p021
12
Automatic operation is put on pause bythe Power
Box
Un-pause automatic operation on the Power
Box or through menu P021
13
All week days are set as inactive days
Validate Inactive Time settings (see Section
6.4.1)
14
The mower is being charged directly by the
Power Box (via the DC connector)
Disconnect the DC cable from the mower. Put
the mower in the Base Station.
15
Battery cells are being balanced in special
charging mode
None. Wait for the end of current charging cycle.
May take longer than usual.
16
The mower is in the Base Station, but there is no
charging voltage supply
- Inspect Power Box’s connection to the Base
Station
- Conrm that nothing is blocking the charging
pins
17
Low ambience temperature
None. The mower will automatically depart
when it gets warmer.
18
Sub-Zone entry problem. The mower was unable
to enter one of the Sub-Zones
Refer to U090-U093 in Section 9.3

Robomow RC306 Specifications

General

Type	Robotic lawn mower
Cutting width	280 mm
Cutting system	-
Recommended lawn area	600 m²
Maximum cutting height	60 mm
Minimum cutting height	15 mm
Grass collecting volume	- L
Battery type	LiFePO4
Power source	Battery
Charging time	1 h
Battery voltage	26 V

Weight and Dimensions

Depth	460 mm
Width	630 mm
Height	210 mm
Weight	11400 g
