Robomow RC308 User Manual

11
EN
3.1.2 “Main Zone + Sub-Zone(s)“ Type Lawn
This type of lawn consists of more than
one zone, where zones are connected by
a narrow pass.
In this type of lawn, Robomow will be able
to drive from one zone to the other in order
to mow the whole area.
If you answer “yes” to all of the following
questions, your lawn is a “Main Zone + Sub-
Zone” type lawn:
o Is your grass area one continuous area?
o Are parts of your lawn separated from the Main Zone?
o Is there a Narrow Pass of at least 1m (3.3 ft.) for Robomow to drive between these zones?
o Is this Narrow Pass rm, in one level and smooth (not stony, sandy or elevated)?
For example: grass area, sidewalk, rm path, solid ground.
Such additional areas are called Sub-Zones.
If your lawn contains a Sub-Zone as dened in this section, refer to Section 6.4.2 (Add Sub-Zone – number
p022 in the table).
Dening Sub-Zone(s) will enable Robomow to drive through the Narrow Pass in order to get to a Sub-Zone and
to mow both the Main Zone and its Sub-Zone(s) one zone at a time.
If your lawn does not match this description, skip to the next Section 3.1.3 of this chapter: “Separate Zones”.
3.1.3 “Separated Zones” Type Lawn
“Separated Zones” type lawn consists of two or more zones that are not connected. Robomow cannot drive
between these zones.
If you answer “yes” to at least one of the following questions, your lawn is of the “Separated Zones” type.
o Are parts of your lawn separated by
fences, sidewalks, or other objects
that Robomow cannot pass?
Or
o Are parts of your lawn separated by
a gravel path or similar material that
may damage the mower blade?
Or
o Are the zones of your lawns joined
by a pass that is too narrow for
Robomow to drive through: less
than 1m (3.3 ft.) in width?
Or
o Are the zones of your lawn situated at lower or higher level?
If your lawn contains a Separated Zone as dened in this section, refer to Section 6.4.2 (Add Separated
Zone - number p014 in the table).
If your lawn does not t any of these descriptions, it is probably either a “Main Zone Only” or
“Main Zone +Sub- Zone” type. Skip to Section 3.3 – Select Base Station and Power Box Location
.
 A lawn may consist of up to 2 Separated Zones .
 The mower must be carried or driven to this area manually.
 Any of the 3 types can be a combination of more than one type of lawn.
Main Zone
Main Zone
Sub-Zone
Main + Sub-Zone with a Narrow Pass
Main Zone
Main Zone
Separated Zone
Separated Zone
Separated Zone
Separated Zone
Main Zone
Main Zone

Robomow RC308 Specifications

General

Type	Robotic lawn mower
Noise level	69 dB
Cutting width	28 mm
Grass catcher	Yes
Product color	Black, Green
Cutting system	Rotary blades
Number of blades	1
Number of wheels	3 wheel(s)
Recommended lawn area	800 m²
Maximum cutting height	60 mm
Minimum cutting height	15 mm
Grass collecting volume	- L
Battery type	Built-in
Power source	Battery
Charging time	90 h
Battery voltage	26 V
Battery life (max)	70 min
Battery technology	Lithium Iron Phosphate (LiFePO4)
Power consumption per month (max)	14 kWh

Weight and Dimensions

Depth	640 mm
Width	460 mm
Height	210 mm
Weight	1140 g
