Robomow RC308 User Manual

29
EN
Chapter 5 – Preparing Robomow
Before using Robomow for the rst time, you have to perform some simple preliminary settings.
Once the preparations are complete, your Robomow will be ready to mow your lawn.
5.1 Adjust the Cung Height
Blade Cutting Range: 15 – 60 mm (0.6 – 2.4 inches)
To adjust the cutting height of the blade, do the following:
CAUTION! ALWAYS TURN THE SAFETY SWITCH OFF
BEFORE ADJUSTING THE CUTTING HEIGHT!
• Lift the front side of the mower.
• Turn the knob while pushing it down.
• To raise the cutting height, turn clockwise.
• To lower the cutting height, turn anticlockwise
• The cutting height is displayed at the side of the mower.
5.2 One-Time Setup (Step by Step)
Make sure the Safety Switch is on and the Power Box is
plugged in before starting the One-Time Setup process.
The mower is now ready to perform the One-Time Setup
process.
! IMPORTANT !
To restart the One-Time Setup process press and hold STOP + Settings + Left
arrow buttons together for more than 4 seconds. This will invoke Factory Defaults (“Out of the Box”
settings).
5.2.1 Using the Operating Panel
Use the buttons on the Operating Panel as follows:
• Press the ‘Right’ or ‘Left’ arrows until your desired option
is displayed.
• Press OK to select the value shown on the display.
• Press ‘Back’ (STOP) to go back or to cancel.
5.2.2 Choose Measurements Units and Formats
Area / Distance Temp. Clock
EU Meter Celsius 24 Hours
US Foot Fahrenheit
12 Hours
(AM / PM)
Safety Switch
HIGHLOW
Cutting height adjustment
HIGH
LOW
ok
STOP
Right/Left arrows
Settings button

Robomow RC308 Specifications

General

Type	Robotic lawn mower
Noise level	69 dB
Cutting width	28 mm
Grass catcher	Yes
Product color	Black, Green
Cutting system	Rotary blades
Number of blades	1
Number of wheels	3 wheel(s)
Recommended lawn area	800 m²
Maximum cutting height	60 mm
Minimum cutting height	15 mm
Grass collecting volume	- L
Battery type	Built-in
Power source	Battery
Charging time	90 h
Battery voltage	26 V
Battery life (max)	70 min
Battery technology	Lithium Iron Phosphate (LiFePO4)
Power consumption per month (max)	14 kWh

Weight and Dimensions

Depth	640 mm
Width	460 mm
Height	210 mm
Weight	1140 g
