Robomow RC308 User Manual

21
EN
If the passage is WIDER than 1.5m:
If the Narrow Pass is wider than 1.5m (5 ft.), and you want Robomow to mow the area inside the Narrow Pass, then
you can set the wire as shown in the gure below. Such a setup allows the mower to mow inside the Narrow Pass
while mowing the inner part of the lawn, but prevents it from crossing between the zones.
1. Dene the entry to the Narrow Pass - the point you want the mower to start driving towards the Sub-Zone.
2. Set an Perimeter Island at the middle of the Narrow Pass (refer to 4.3.2) as shown in the picture above and
keep a distance of 10 cm (4 inches) from the Perimeter Wire.
3. The island dimensions should be 28 cm (11”) along the side and as wide as needed, when keeping 10 cm (4
inches) from both sides.
4. After completing the setup of the wire in the Sub-Zone, make sure you keep 10 cm (4 inches) between the wire
and the island on the way back to the Main Zone.
10cm
Sub-Zone
28cm
Min. 50cm
2 Wires under
same peg
10cm
Main-Zone
Good VS Bad Narrow Pass:
The following drawing illustrates a good (at) vs bad (bumpy) narrow passage.
Sub Zone
Main Zone
Main Zone
Sub Zone

Robomow RC308 Specifications

General

Type	Robotic lawn mower
Noise level	69 dB
Cutting width	28 mm
Grass catcher	Yes
Product color	Black, Green
Cutting system	Rotary blades
Number of blades	1
Number of wheels	3 wheel(s)
Recommended lawn area	800 m²
Maximum cutting height	60 mm
Minimum cutting height	15 mm
Grass collecting volume	- L
Battery type	Built-in
Power source	Battery
Charging time	90 h
Battery voltage	26 V
Battery life (max)	70 min
Battery technology	Lithium Iron Phosphate (LiFePO4)
Power consumption per month (max)	14 kWh

Weight and Dimensions

Depth	640 mm
Width	460 mm
Height	210 mm
Weight	1140 g
