Roborock Q7+ - Product Overview; Robot Components; Auto-Empty Dock Components

06
Product Overview
A
A1
Robot (Top View)
A2
Robot (Bottom View)
A3
Robot (Upper Cover Open)
A3-1—WiFi Indicator Light
A6-1—Water Tank Stopper
A6-2—Filter Components
A6-3—Water Tank
A6-4—Water Tank Latch
A6-5—Flow Control
A5
Mop Cloth
A5-1—Mop Cloth
A5-2—Hook and Loop Pads
A2-1—Wall Sensor
A2-2—Cli Sensors
A2-3—Omni-Directional Wheel
A2-4—Charging Contacts
A2-5—Side Brush
A2-6—Main Wheel
A2-7—Main Brush
A2-8—Main Brush Cover Latches
Note: Press any button to stop the robot during cleaning or
docking.
A1-1—Bumper
A1-2—LiDAR Sensor
A1-3—Cover Opener
A1-4—Dock Locator
•
O: WiFi disabled
•
Flashing slowly: Waiting for connection
•
Flashing quickly: Connecting
•
Steady: Connected
•
Press to return to dock
•
Press and hold to start spot cleaning
—Docking/Spot Cleaning
•
Press and hold to turn the robot on
or o
•
Press to start cleaning
—Power/Clean
•
White: Battery level
≥
20%
•
Red: Battery level < 20%
•
Pulsing: Charging or starting up
•
Flashing red: Error
—Power Indicator
A4
Dustbin
A4-1—Dustbin Latch
A4-2—Washable Filter
A3-2—Reset Button
A3-3—Air Outlet
A6
Adjustable Water Tank
A7
Disposable Dust Bag
A8
Base
A8-1—Air Duct Cover Screws (10)
A8-2—Air Duct Cover
A8-3—Screwdriver
A8-4—Base Fastening Screws (6)
A11
Power Cable
A9-8—Power Cable Storage Slot
A9-9—Cable Outlet
A9-10—Power Port
A10
Auto-Empty Dock (Cover
Removed)
A10-1—Dust Bag Slot
A10-2—Filter
Note: Power cable can exit at either side.
A9
Auto-Empty Dock
A9-1—Dustbin Cover
A9-2—Dustbin (Disposable Dust Bag
Pre-Installed)
A9-3—Status Indicator Light
A9-4—Dock Location Beacon
A9-5—Charging Contacts
A9-6—Suction Inlet
A9-7—Electrode Brushes
•
Steady white: Standby
•
Flashing white: Emptying
•
Steady red: Malfunction
•
Light o: Charging Robot/Not
Powered On
Installation
B
B1
Important Information
B1-1—Tidy cables and loose items from
the ground and move any unstable,
