007
A3
Robot (Upper Cover Open)
A3-1—WiFi Indicator light
A6
VibraRise Mop Bracket
A6-1—Vibration Module
A6-2—Mop Cloth Attachment Slot
A6-3—Mop Bracket Latches
A7
VibraRise Mop Cloth
A8
Power Cable
A9
Dust Bag Holder
A10
Disposable Dust Bag
A11
Screwdriver
A7-1—Hook and loop pads
• Off: WiFi disabled
• Flashing slowly: Waiting for
connection
• Flashing quickly: Connecting
• Steady: WiFi connected
A5
Electric Water Tank
A5-1—Stopper
A5-2—Water Filter
A5-3—Water Tank Latch
A5-4—Self-Filling Port
A4
Dustbin
A3-2—Reset Button
A3-3—Air Inlet
A3-4—LiDAR Sensor
A3-5—Mop Wash Sensor
A3-6—Water Tank Latch
A3-7—Positioning Button
A3-8—Water Tank
A3-9—VibraRise Module
A3-10—Air Outlet
Dock
Spot Clean/Child Lock
A1
Robot (Top View)
• Press to return to dock/start
emptying
Press any button to stop the robot during cleaning
or docking.
Note:
Only available in the Roborock app.Note:
A1-1—Vertical Bumper
A1-2—Microphone
A1-3—Status Indicator Light
A1-4—Wall Sensor
A1-5—Bumper
A1-6—Charging Contacts
A1-7—ReactiveAI Obstacle Recognition
A1-8—LED Fill Light
• Press to Spot clean
• Press and hold for 3 seconds to
turn on/off the child lock
• For use with Video Calls
• White: Vacuuming
• Blue: Vacuuming and Mopping
• Orange: Alert
• Green: Docking/Recharging
• White: Battery level ≥ 20%
• Red: Battery level < 20%
• Pulsing: Charging or starting up
• Flashing red: Error
Power Indicator
Power/Clean
• Press and hold to turn the robot
on or off
• Press to start cleaning
Product Overview
A
A2
Robot (Bottom View)
A2-1—Cliff Sensors
A2-2—Carpet Sensor
A2-3—Omni-Directional Wheel
A2-4—Charging Contacts
A2-5—Side Brush
A2-6—Main Wheel
A2-7—Main Brush
A2-8—Main Brush Cover Latches
A4-1—Filter Cover
A4-2—Dustbin Latch
A4-3—Cover Latch
A4-4—Air Inlet
A4-5—Washable Filter
