13
Lift the dustbin and remove the
bag vertically as shown.
Carefully place the dock upside
down on a hard floor covered with
a soft towel.
Unscrew the three screws and
remove the cover.
Wipe the air duct and duct cover
with a dry cloth.
Reinstall the cover and screw it
back in place.
Discard the dust bag and clean
around the filter with a dry cloth.
Slot in a new disposable dust bag
as shown. Slide until it reaches the
bottom of the slot and reinstall the
dustbin securely.
The chemical substances contained in the built-
in lithium-ion battery of this product can cause
environmental pollution. Remove the battery
before disposing of this product and hand it
to a professional battery recycling facility for
centralized disposal.
1. Operate the robot without connecting to the
dock until it runs out of battery.
2. Turn off the robot.
3. Unscrew the battery cover.
4. Remove the battery cover.
5. Press the latch to pull out the battery
connector and remove the battery.
*
Replace the disposable dust bag when it is full.
*
The following information applies only when disposing
of the robot and should not be followed for day-to-day
operations.
Removing the Battery
Note: Pulling the dust bag handle to remove the bag will seal
the bag to prevent leakage.
Note: Always install a dust bag before putting back the
dustbin top lid to avoid auto-emptying without the bag. You
can also disable auto-emptying in the app.
C14-1—
C15-4—
C15-5—
C15-6—
C15-7—
C14-2—
C14-3—
C14
Replacing the Disposable
Dust Bag
*
Clean as required.
Remove the clean water tank, dirty
water tank, and dustbin.
Remove the water filter and wipe
off any water marks with a cloth.
Grasp the sides of the dock base
upward to disassemble and check
any blockage. Clean the air inlet
with a cotton swab if it gets blocked
and wipe it with a dry cloth.
Follow the following steps to clean the air
duct and avoid blockages.
C15-1—
C15-2—
C15-3—
C15
Cleaning the Air Duct
Basic Parameters
Environment
Protection Information
Robot
Note: The serial number is on a sticker on the underside of
the robot.
Empty Wash Fill Dock
Model S81USP
Battery
14.4V/5200mAh (TYP)
lithium-ion battery
Rated Input 20V
1.5A
Charging Time Approx. 4 hours
Model
EWFD07LRR,
EWFD08LRR
Rated Input Voltage 120V~
Rated Frequency 60Hz
Rated Input
(Dust Collection)
9.5A
Rated Input
(Non-Dust Collection)
1.2A
Rated Output 20V
1.5A
Charging Battery
14.4V/5200mAh (TYP)
lithium-ion battery
Notes:
• Before removing the battery, make sure it is fully drained. Do
not attempt to remove the battery if the robot is connected to
the dock.
• Remove the entire battery pack. Avoid damaging the battery pack
casing to avoid short-circuits or leakage of hazardous substances.
• In the event of accidental contact with battery fluid, rinse
thoroughly with water and seek immediate medical care.
