Press any button to stop the robot during cleaning
or docking.
Dock
Spot Clean/Child Lock
Product Overview
A
A1
Robot (Top View)
A2
Robot (Bottom View)
A4
Dustbin
A3
Robot (Upper Cover Open)
A3-1—WiFi Indicator Light
• Press to return to dock/start emptying
Note:
A1-1—Vertical Bumper
A1-2—LiDAR Sensor
A1-3—Wall Sensor
A1-4—Reactive 3D Obstacle Avoidance
Sensor
A1-5—Infrared Fill Light
• Off: WiFi disabled
• Flashing slowly: Waiting for connection
• Flashing quickly: Connecting
• Steady: WiFi connected
• Press to Spot clean
• Press and hold for 3 seconds to
turn on/off the child lock
A5
Power Cable
A6
Electric Water Tank
A7
VibraRise Mop Cloth Mount
A8
VibraRise Mop Cloth
A7-1—Vibration Module
A7-2—Mop Cloth Attachment Slot
A7-3—Mop Cloth Mount Latches
A8-1—Hook and loop pads
A6-1—Stopper
A6-2—Water Filter
A6-3—Water Tank Latch
A4-1—Filter Cover
A4-2—Dustbin Latch
A4-3—Cover Latch
A4-4—Air Inlet
A4-5—Washable Filter
A3-2—Reset Button
A3-3—Water Tank Latch
A3-4—Water Tank
A3-5—VibraRise Module
A3-6—Air Outlet
A3-7—Bumper
• White: Battery level ≥ 20%
• Red: Battery level < 20%
• Pulsing: Charging or starting up
• Flashing red: Error
Power Indicator
Power/Clean
• Press and hold to turn the robot
on or off
• Press to start cleaning
A2-1—Cliff Sensors
A2-2—Carpet Sensor
A2-3—Omnidirectional Wheel
A2-4—Charging Contacts
A2-5—Side Brush
A2-6—Main Brushes
A2-7—Main Brush Cover
A2-8—Main Wheels
A9
Dustbin (Disposable Dust
Bag Pre-Installed)
A10
Dustbin Cover
A11
Disposable Dust Bag
A12
Base
A12-1—Air Duct Cover Screws (10)
A12-2—Air Duct Cover
A12-3—Screwdriver
A12-4—Base Fastening Screws (6)
A13
Auto-Empty Dock
A13-1—Dustbin Cover
A13-2—Dustbin
A13-3—Base
A13-4—Status Indicator Light
• Steady white: Standby
• Flashing white: Emptying
• Steady red: Malfunction
• Light off: Charging Robot/Not
Powered On
